Kernel filesystem

As explained in Podman in Action: Secure, rootless containers for Kubernetes, microservices, and more

A kernel filesystem is a filesystem interface exposed by the operating-system kernel for representing kernel-managed information or resources.

A kernel filesystem is a kernel-provided interface, commonly mounted under /proc or /sys, that exposes information or controls for kernel-managed resources. Containers generally need to read these filesystems, but unrestricted writes could compromise the host. Podman therefore limits, masks, or mounts selected kernel filesystems read-only. section 10.1 section 1.2

Podman applies several boundaries to kernel filesystem access:

  • Mounts /sys, /sys/fs/cgroup, and /sys/fs/selinux read-only while providing a namespaced /proc inside the container. section 10.1
  • Masks sensitive paths such as /proc/kcore, /proc/keys, /proc/sys, and /sys/firmware with read-only temporary or bind mounts. section 10.1
  • Combines filesystem restrictions with mount namespaces, SELinux, capabilities, seccomp, and user namespaces rather than defaulting to --privileged. section 10.0 section 1.2

Container access boundary

A process inside a PID namespace sees the container’s /proc rather than the host’s /proc and can affect only processes within that namespace. An application needing a masked directory may require carefully scoped additional access. section 10.1

Table 10.2 Filesystem fields masked over with Podman (view table figure)

Type of masking

Paths

Read-only tmpfs mounted over the directory

/proc/acpi, /proc/kcore, /proc/keys, /proc/latency_stats, /proc/timer_list, /proc/timer_stats, /proc/sched_debug, /proc/scsi, /sys/firmware, /sys/fs/selinux, /sys/dev/block

Read-only bind mount over the directory

/proc/asound, /proc/bus, /proc/fs, /proc/irq, /proc/sys, /proc/sysrq-trigger

Browse the complete list of filesystem paths Podman masks and the mount treatment applied to each. section 10.1

How Podman in Action: Secure, rootless containers for Kubernetes, microservices, and more covers it

How deep it goes
Explains /proc and /sys mounts, namespaces, read-only treatment, and masking, but stops short of detailed configuration procedures.
Examples
Uses /proc, /sys, /sys/fs/cgroup, /sys/fs/selinux, and Podman-masked paths such as /proc/kcore and /sys/firmware.
What it assumes
Assumes familiarity with Linux processes, filesystems, and administrator privileges while defining container isolation mechanisms.
What you can do after
Evaluate container access failures and avoid using --privileged as the first response to denied kernel filesystem access.
How it connects
Connects kernel filesystems with mount namespaces, PID namespaces, SELinux, Linux capabilities, seccomp, user namespaces, and cgroups.
